S9600-28DX
Open Aggregation Router






S9600-28DX
28-Port, 100/400G 開放式聚合路由器
- 400G Multi-function Aggregation Router
- Supports TSN, SyncE and IEEE 1588
- 4 x 40/100/200/400G QSFP-DD ports supporting 400G ZR/ZR+
- 24 x 40/100G QSFP28 ports
- 4 x 1/10/25G SFP28 (In-band port share with 100GE Port 0)
- 1 x RJ45 serial console port
- 1 x Micro USB console port
- 1 x 100/1000M RJ45 management port
- 1 x USB 3.0 Type-A general purpose port
- GNSS, 1PPS, 10MHz, and ToD timing ports
概論
The S9600-28DX open aggregation router, is a multi-function, white box aggregation routing platform. It is equipped with Broadcom's Qumran2c merchant silicon chip with Intel's Icelake processor. The platform features 24x100G and 4x400G high speed ports with a switching capacity of up to 2.4Tbps.
The S9600-28DX can be deployed at C-RAN hubs to provide 5G fronthaul transport aggregation, positioned at the backhual for aggregating BBU pools or be programmed to be a Broadband Network Gateway (BNG) to enable next generation broadband network. Supporting OpenZR+ makes it an idea solution for metro aggregation.
Specializing in 5G time-critical applications, the S9600-28DX can act as an Edge Grand Master (T-GM) or Boundary Clock (T-BC). Our open aggregation router is compatible with high accuracy fronthaul synchronization and timing requirements to ensure error free operation of 5G and cooperative radio techniques.
For additional information or samples of our S9600-28DX, please contact our sales team.
特色
- Utilizes UfiSpace timing module for Class C timing accuracy
- Supports SyncE and IEEE 1588v2 (T-GM, T-BC/OC, T-TC, T-TSC)
- Integrated Stratum 3E OCXO with optional hold over performances
- Rich timing input/output interfaces: ToD, 1PPS and 10MHz
- Internal GNSS receiver for master clock implementations
- 4GB deep buffering
- BMC for remote monitoring and management
- 2 hot swappable power supplies with 1+1 redundancy support.
- 4 hot swappable fan modules with 3+1 redundancy support.
- 2 RU compact design, suitable for industry standard 19" racks.
For additional information or samples of our S9600-28DX, please contact our sales team.
規格
S9600-28DX的產品各類相關文件或樣品需求,歡迎聯繫我們的銷售團隊
硬體規格
處理器 | Intel Icelake-D 8-Core @ 2.1GHz |
記憶體 | 32GB DDR4 |
儲存技術 | 128GB SSD |
ASIC | Broadcom Qumran2c BCM88820 |
BMC | AST2620 |
機箱規格 | 2RU, 436W x 762D x 87.7H mm (17.17" x 30" x 3.45") Weight: 17.66 kg (38.93 lbs) |
備援配置 | 1+1 Hot swappable power units 3+1 Hot swappable fan units |
環境規格
電源規格 | AC input: 100 to 240V, 12A DC input: -40 to -75V, 40A Typical power: 324 Watts (no transceiver) |
操作環境規格 | Operating temperature: 0°C to 45°C (32°F to 113°F) Operating humidity: 5% to 85% (RH), non-condensing |
儲存環境規格 | Storage temperature: -40°C to 70°C (-40°F to 158°F) Storage humidity: 5% to 93% (RH), non-condensing |
